- For Wall and In-Ceiling Mount
- Resolution of 380 Horizontal Lines
- Built-in Pinhole Lens F2.0/3.7 mm
- Electronic Shutter Control (ESC)
- Internal Synchronization
- Easy Installation
- Supply Voltage: 12 VDCbr> -Video Standard: PAL
-System: Colour
-Sensor size: 1/3"
-Imager: CCD, Sony Super HAD Interline Transfer CCD
-Picture elements: Approx. 290,000, 500(H) x 582(V)
-Synchronization: Internal
-Sensitivity (at 50% video signal): 2,0Lux, at F1.2, 5.4Lux at F2.0 (VT measurement result)
- Horizontal resolution: 380TVL
- Rotation range: 360°
- Tilt range: Approx. +/-60°
- Gamma correction: 0.45
- Integration rate: No
- Backlight compensation: No
- IR cut fitler: No
- Video outputs (type): CVBS
- Video outputs: 1Vp-p, CVBS, 75ohms
- Lens mount: Integrated lens
- Lens type:: Fixed focal length
- Lens: F2.0/3.7mm Pinhole
- Application range: Security
- Nominal format size: 1/3"
- Aspherical technology: Not Available
- Focal length: 3,7mm
- Horizontal angle of view: 68°
- Iris control: No
- Mount: Not Available
- External connections: Video (BNC), 12VDC (Cinch)
- Serial interfaces: No
- Temperature range (Operation): -10°C ~ +40°C
- Heater: No
- Protection rating: Not Available
- Supply voltage: 12VDC
- Power consumption: 2.2watts max.
- Colour (bubble): Not Available
- Camera fixing: No
- Mounting: In-ceiling mount, wall mount
- Housing: Indoor housing
- Housing material: Aluminium
- Colour (housing): Anodized light (C-0)
- Weight: 125g
Accessories:
VT-PS12DC-5
Plug-in Power Supply Unit 100-240VAC 12VDC (1.0Amp), Regulated, with DC Plug
VT-PS12DC-UK
Power Supply Unit w. UK Mains plug-in, 100-240VAC/12VDC-1.0A, Regul., open Ends
VT-PS12DCDT1
PSU 12VDC/1.0A, Regulated, Desktop Version, 1.8m Cables each w. open ends
